PP SS Spunbond Nonwoven Fabric Making Machine

Model No.

GL-SS

Equipment size

29x13x11 m

Speed

350 m/min

Gram Weight

10-150 g/m2

Product Description

Guanlong has been focusing on non-woven fabric making Lines for 15 years. We combine international advanced technology and customers’ production need, provider various holistic solutions for customers. At present, we have manufactured hundreds of full-automatic production lines for customers all over the world.

The following is the advantages of SS Spunbond Nonwoven Machine

1. SS Nonwoven Machine Adopts an intelligent electrical control cabinet and spinning drafting system. The system controlling mode features in advanced AC frequency-modulated speed, fully digital synchronized communications.
2. SS Nonwoven Machine is double-beam, owns obvious higher quality as well as obvious larger quantity in production than S Nonwoven Machine.
And SS Nonwoven Machine runs in high efficiency and low power consumption. Based on the features above, SS Nonwoven Machine can help customers to save labor and wide compatibility with different high requirements of productions.
3. SS Nonwoven Machine is the professional manufacturer in double layers non-woven fabric.
a) About the process: SS Nonwoven Machine is manufactured for PP/PET/PLA/Bi-Component Spunbond non-woven fabrics’ production. After the raw materials input, undergo the process of extrusion, spinning, quenching, closure air stretching, web formation, calendaring, winding and cutting as per requirements and then packed for storage and delivery.
b) About the fabric: as the fabrics have greater intensity, better breath-ability, and better feeling, they are widely used for various fields such as medical and health, beauty care products, hygienic products, industrial and agricultural protective covers, parking linning and so on.
4. About the package: we pack the main machine parts in wooden cases; the electrical parts will be packed with plastic and then packed into wooden cases; With the steel structure, they will be packed into containers.

The main specifications of SS Nonwoven Machine:

Model No.GL-SS
SS(product width)1600 mm2400 mm3200 mm
Equipment size29x13x11 m30x14x11 m30x15x11 m
Speed350 m/min350 m/min350 m/min
Gram Weight10-150 g/m210-150 g/m210-150 g/m2
Yield(Products according to 40 g/m2)9-10 T/DAY13-14 T/DAY18-19 T/DAY



ModelEffective widthDaily capacitySpeedSpinning systemGSM RangeMachine dimension
Length*Width*Height
HG-1600M1600MM2000Kg100M/MinMeltblown10-20015*8*8 meter
HG-2400M2400MM3000Kg15*10*8 meter
HG-3200M3200MM4000Kg15*12*8 meter
HG-1600S1600MM5000Kg200M/MinSpunbond10-20020*8*11 meter
HG-2400S2400MM7000Kg(S)20*11*11meter
HG-3200S3200MM10000Kg20*15*11meter
HG-1600SS1600MM9000Kg350M/MinSpunbond8-15035*10*11meter
HG-2400SS2400MM13000Kg(SS)35*12*11meter
HG-3200SS3200MM16000Kg35*15*11meter
HG-1600SSS1600MM12000Kg400M/MinSpunbond8-10040*10*11meter
HG-2400SSS2400MM16000Kg(SSS)40*12*11meter
HG-3200SSS3200MM23000Kg40*15*11meter
HG-1600SMS1600MM10000Kg400M/MinSpunbond/8-8040*15*11meter
HG-2400SMS2400MM14000KgMeltblown/40*18*11meter
HG-3200SMS3200MM18000KgSpunbond/40*25*11meter
HG-1600SMMS1600MM12000Kg500M/MinSpunbond8-8045*15*11meter
Meltblown
HG-2400SMMS2400MM17000KgMeltblown45*18*11meter
HG-3200SMMS3200MM23000KgSpunbond45*25*11meter
